DC Load Bank PDL 500-80K — 80 kW - front view PDL
Load Banks

DC Load Bank PDL 500-80K — 80 kW

Product seriesPDL Exact modelPDL 500-80K Rated power80 kW Installation & mobilityMobile / caster-mounted

Niawell PDL 500-80K 80 kW programmable DC load bank for controlled battery discharge testing from 10 to 500 VDC.

Device models

Mobile / caster-mounted PDL 500-80K 80 kW · 500 V Mobile / caster-mounted PDL 500-40K 40 kW · 500 V
Industrial engineering Custom configurations Engineering support
Request a quotation Specifications
OVERVIEW

About this model

Niawell PDL 500-80K 80 kW programmable DC load bank for controlled battery discharge testing from 10 to 500 VDC.
ENGINEERING SELECTION GUIDE

80 kW programmable DC load bank for DC power testing

The PDL 500-80K is a programmable DC load bank rated at 80 kW. Its higher rating compared with the 40 kW model does not imply unlimited voltage or current operation; verify the limits from this exact model's specifications.

Typical test applications

  • Apply controlled load to industrial DC power supplies
  • Assess battery discharge performance under an approved plan
  • Monitor source behaviour at defined load points

Confirm before specifying

  • Required power, source voltage and current
  • Documented operating envelope for the 80 kW model
  • Safe connections, cooling and test stop criteria

Engineering questions

How does it differ from PDL 500-40K?

Its rated power is 80 kW rather than 40 kW. Compare the two models' exact voltage, current and operational limits separately.

Is it suitable for battery testing?

It can be considered for suitable DC tests, provided discharge current, cut-off voltage and battery-maker requirements are verified.

What information is needed for a quotation?

Provide source voltage and current, requested load and duration, installation location and safety requirements.

Need model-specific engineering advice?

Prepare source ratings, voltage, power, test duration and site details.

TECHNICAL DATA

Exact technical specifications

The data below comes directly from this exact model record and is never substituted with another power rating.

Select a model. Scroll the desktop comparison table horizontally to see all models.

Compare series modelsChoose a model above; mobile shows only the selected model.
Specification PDL 500-80K 80 kW · 500 V PDL 500-40K 40 kW · 500 V
Technical Specifications
Model PDL 500-80K PDL 500-40K
Load TypeShared Programmable DC Load Bank
Rated Power 80 kW 40 kW
Input Voltage RangeShared 10–500 VDC
Operating ModesShared Constant current, constant power and constant resistance
Reverse Polarity ProtectionShared Yes
CoolingShared Forced-air cooling
Control SystemShared CSU supervisory control unit
Auxiliary SupplyShared 220 VAC, 50 Hz
Dimensions (W × L × H) 46 × 95 × 75 cm 35 × 78 × 50 cm
Weight 85 kg 55 kg
Power SwitchingShared IGBT and MOSFET
Operating TemperatureShared 0–50 °C, indoor use
ApplicationsShared Battery discharge testing and DC power-supply testing
PDL

PDL 500-80K

80 kW · 500 V

Model
PDL 500-80K
Load Type
Programmable DC Load Bank
Rated Power
80 kW
Input Voltage Range
10–500 VDC
Operating Modes
Constant current, constant power and constant resistance
Reverse Polarity Protection
Yes
Cooling
Forced-air cooling
Control System
CSU supervisory control unit
Auxiliary Supply
220 VAC, 50 Hz
Dimensions (W × L × H)
46 × 95 × 75 cm
Weight
85 kg
Power Switching
IGBT and MOSFET
Operating Temperature
0–50 °C, indoor use
Applications
Battery discharge testing and DC power-supply testing
